Light intensity Detector

Published Sep 19, 2022

Apache-2.0

20 hours to build

Beginner

msp430-launchpad

A sunlight ray interpreting is a device which is having an application in finding a suitable place for installing the solar plates. It is governed with the help of a microcontroller msp430 and Light Dependent Resistor (LDR)sensors, a Light Dependent sensor which will keep watch the frequency of sunlight falling on it.

Components Used
LDR -Photocell Photoresistor LDR -Photocell, Photoresistor	X 1
Resistor 10K 0603 Resistor 10K 0603	X 1
Connecting Wire Jumper Wires Connecting Wire Breadboard wires	X 1
LED 3mm LED 3mm	X 1
LCD 16x2 Display Module LCD16x2 has two lines with 16 character in each line. LCD16x2 is generally used for printing values and string in embedded application.	X 1
MSP430G2553 16-bit Microcontroller 16-bit Microcontrollers - MCU Mixed Signal MCU	X 1
Potentiometer 10Kohms Potentiometers 10Kohms 10% 12.5mm Cermet Element	X 1
Breadboard Breadboard	X 1
Wire Hook-up Wire 788133 RED 100 FT	X 1
Wire Stripper and Cutter Wire Stripper and Cutter	X 1
Male to Female Jumper Wire Jumper Wires Mach pin jumper wires	X 1
Female to Female Jumper Wire Jumper Wires Mach pin jumper wires	X 1
Male to Male Jumper Wire Jumper Wires Mach pin jumper wires	X 1

Description

Description

Light Dependent Resistor (LDR)

The Light dependent resistor is connected to Port 1, +5V (configured to act as input channel for the ADC). The SAR ADC on MSP430 converts the analog values supplied by the LDR to digital values. The LDR is connected in a voltage divider circuit with a 10K Ohm's resistor
